SERIES – E30 – FLAT TOP
• Pitch = 30 mm
• Open area = 0%
• Thickness = 10 mm
• Rod diameter = Ø 4.6 mm
-
BKP-H708
-
E925 – SPROCKETS
Gears with rounded edges and open holes for easy cleaning. Chamfered teeth prevent skipping.
-
E93 – SPROCKETS
We also have sprockets to be used with motor drum in applications needing a special cleaning or in conveyors in which it is not possible to place the motor in the outside due to problems of space or safety.
To calculate the necessary minimum quantity of sprockets for the drive shaft as well as for the idle one, the next formula has been used:
This quantity must always be odd.
-
E93 – FLIGHTS
The flights are plastic accessories to be inserted across the belt. They are used to push the product in ascent, descent or accompaniment applications, avoiding that it slips along the belt.
• Its non-stick side has ribs that project over the surface to prevent the product from sticking.
• Their edges are completely rounded to avoid any damage of the product.
• They can be used both in right and in curve sections.It is possible to cut down the standard height for special applications.
-
BKP-H702
สิà¸à¸à¹à¸²à¸¡à¸²à¹à¸«à¸¡à¹ - JUST ARRIVED
-
E32 – FLAT TOP
Eurobelt Series E32 Flat Top has a one-only-piece geometry in different widths: 82.5 – 114.3 – 152.4 – 190.5 mm. It has two down-tracking tabs that keep the conveyor belt aligned counteracting the lateral forces. Its maintenance is greatly reduced as no lubrication is required for its good performance.
-
E31 – LATERAL TRANSFER
Eurobelt Series E31 Lateral Transfer, with a one-only-piece geometry 152.4 mm wide, is bevelled in one of its side edges to enable the approach to the belt delivering the product, as well as down-tracking tabs in order to assure its alignment. This conveyor belt has been designed to carry out lateral dynamic transfers of containers in perpendicular crossing lines.
-
E40 – SLIDING ROLLERS
Eurobelt Series E40 Sliding Rollers is provided with small rollers inserted on its surface that rotate around themselves whenever there is product accumulation, avoiding crushing and wear in the base of the product.
This conveyor belt has been designed mainly to solve problems of conveyance of boxes, containers, etc. -
E40 – NON SLIP
Eurobelt Series E40 Non Slip has a closed surface with a relief specially designed to avoid slips. Both its high resistance to traction and to chemical aggression of oils and industrial acids make it be the suitable belt for assembly lines in the car industry, for conveying people, furniture, electrical appliances, etc.
This conveyor belt is manufactured in conductive materials to disperse the electrostatic charges through the conveyor frame.
-
E40 – FLUSH GRID
Eurobelt Series E40 Flush Grid has a grille-shaped configuration with a 14% open area, and a completely smooth surface. Due to the specific study carried out, it is one of the strongest belts in the market, having an excellent drainage capacity.
It is ideal for those applications which require a great belt resi -
E40 – FLAT TOP
Eurobelt Series E40 Flat Top, given the closed surface configuration, is the suitable conveyor belt for those applications in which it is not necessary any drainage through the belt and/or the product to be transported is small.
Due to its great mechanical resistance, it is ideal for applications having large conveyance lengths or bearing very heavy loads. -
E40 – FLIGHTS AND SIDE GUARDS
The flights are plastic accessories to be inserted across the belt. They are used to push the product in ascent, descent or accompaniment applications, avoiding that it slips along the belt.
Its non-stick side has ribs that project over the surface to prevent the product from sticking.
It is possible to cut down the standard height for special applications.
Materials: Polypropylene – Polyethylene – Polyacetal
-
E41 – RAISED RIB
Eurobelt Series E41 Raised Rib conveyor belt, given its configuration of projecting ribs, enables us to make product transfers by using finger plates.
The central reinforcement of the ribs allows the lateral entrance of cans, glass jars, or containers in general, avoiding their overturning as well as any damag -
E41 – FINGER PLATES
They have been designed to be used with the Raised Rib belts in applications in which it is necessary to transfer the product by means finger plates.
The finger plates are manufactured in nylon and acetal. They have 15 teeth that hide among the projecting ribs of the belt, allowing the constant flow of product as the belt is engaged. They avoid the use of conventional dead plates and consequently the problems by stumbling and fall of the product.
They have three fastening holes that enable little displacements to achieve a better coupling with the belt. Those holes are located so that they reduce to the minimum the vibrations owing to the turn of the belt over the sprockets.
The finger plates can be easily installed in the structure of the conveyor putting a screw in each hole. The dimensions of these screws are: M 6 x 19 mm.
-
E50 – SLIDING ROLLERS
Eurobelt Series E50 Sliding Rollers is provided with small rollers inserted on its surface that rotate around themselves whenever there is product accumulation, avoiding crushing and wear in the base of the product.
This conveyor belt has been designed mainly to solve problems of conveyance of boxes, containers, etc. -
E50 – PERFORATED
Eurobelt Series E50 Perforated Flat Top has an 18% open area, a completely smooth surface, and grille-shaped small straight holes without structural obstacles, to make easy the drainage of any liquid.
The dimensions of these holes, in millimetres, are:
[1.8 x 6], [2 x 9] and [2 x 15]. -
E50 – OPEN GRID
Eurobelt Series E50 Open Grid, with a grille-shaped configuration, and a 40% open area, is suitable for applications in which drainage through the belt is required.
We have accomplished an exclusive design of this conveyor belt consisting of two transverse projections in the middle of every pitch to achieve the product do not adhere to the belt..
